Widths
These are (my) standard HP sizes:
- 60HP = 306mm + 2x 12mm sides = 330mm
- 84HP = 428mm + 2x 12mm sides = 452mm
- 104HP = 530mm + 2x 12mm sides = 554mm
- 126HP = 642mm + 2x 12mm sides = 666mm
- 160HP = 814mm + 2x 12mm sides = 838mm
- 196HP = 997mm + 2x 12mm sides = 1021mm
- I cut the rails to size myself, so other HP possible on request
Eurorack case for Henry
configurator
Hello Henry, welcome to my ‘Eurorack configurator’, here you can select all options available to configure your perfect Eurorack case!
All orders are made-to-order, so you can select all options here and see how they inflict the price.
Standard sizes go from 6U to 25U in height and in width from 60HP to 200HP
Custom dimensions and configurations are possible on request.
Standard the rails is in aluminum colour, but optionally it can be replaced by a black version.
Please select a multitude of this per 1U or 3U row, so if you order a 9U case you'll have 3x 3u = 3 rows x black surplus.
For the M3 slide nuts, you can select them as a multitude of 20 pcs, just select roughly how many you would like in your complete case and they will be distributed accordingly.
For the threaded inserts you need to select the number of pairs you need per 1U or 3U row; so with 3U just 1x, with 6U you'll need 2x, etc. Note that the inserts have a maximum length from the factory, so with larger cases they can be build up out of two pieces.
There are 2 options by Konstantlab:
HammerPWR & SeventyPWR are externally powered from a power brick. This creates the option to fully wire the system for you and ready to go, since there is no high voltage inside the case. These power supplies have been developped for Eurorack specifically, are known for their power & low noise but to come at a cost.
- HammerPWR (100 Watt output) + MeanWell 120Watt adapter, +12V 5A (2x 2.5A), -12V 2.5A and +5V 2.0A
- SeventyPWR (70 Watt output) + MeanWell 90 Watt adapter, +12V 2.5A, -12V 2.5A, +5V 2.0A
The Meanwell RT-65B is a low cost and efficient power supply, giving loads of power for a good price. By far the most popular and most sold PSU for Eurorack. The PSU's always come mounted to the case. The power is either DIY or pre-wired on all low-voltage wires & ground. The final connection from the socket to the PSU has to be done by yourselves (no soldering, only cable stripping & a few screws).
RT-65B Specs: +12V 3.5A -12V 1.0A and 5V 8.0A, total output power 65W.
Power to your modules are supplied by bussboards
When you select a MeanWell PSU you'll get the Modular Synth Lab Bussboards with 20 headers, when you select a HammerPWR or SeventyPWR you automatically get the Konstantlab's filtered bussboards with 19 connectors each.
Recommended to have a maximum of 3 or 4 bussboards per PSU.
Choose for a DIY cable kit and assemble it yourselves/with local help. or choose for a system where all low-voltage cables have been pre-wired! For the HammerPWR & SeventyPWR PSU this means that the case is ready to go, with the Meanwell RT65B you'll only need to connect the socket(s) to the PSU('s).
1 power socket for 3x MeanWell PSU's max. to not exceed the 10A fuse, otherwise select multiple.
Available on backorder
